11 www.rosscontrols.com
Function*
4-Way
2-Position
Remote Pilot 56
Solenoid Pilot 76
4-Way
3-Position
Remote Pilot 57
Solenoid Pilot 77
Dual 3-Way
2-Position
Normally
Open
70
Normally
Closed
75
NC / NO
NC - 14 End
78
Series W66 Valve Ordering Code
W66 76 A 0 4 01 W
Options*
4-W
ay 2-Position
Single
Plug-In (15407-2)
Non-Locking Overrides
Internal Pilot - 01
External Pilot - 51
Locking Overrides
Internal Pilot - 11
External Pilot - 21
Drop Cord (15407-1)
Non-Locking Overrides
Internal Pilot - 61
External Pilot - 81
Locking Overrides
Internal Pilot - 71
External Pilot - 91
Double
Plug-In (15407-2)
Non-Locking Overrides
Internal Pilot - 07
External Pilot - 57
Locking Overrides
Internal Pilot - 17
External Pilot - 27
Drop Cord (15407-1)
Non-Locking Overrides
Internal Pilot - 67
External Pilot - 87
Locking Overrides
Internal Pilot - 77
External Pilot - 97
4-W
ay 3-Position
Closed
Center
Plug-In (15407-2)
Non-Locking Overrides
Internal Pilot - 01
External Pilot - 51
Locking Overrides
Internal Pilot - 11
External Pilot - 21
Drop Cord (15407-1)
Non-Locking Overrides
Internal Pilot - 61
External Pilot - 81
Locking Overrides
Internal Pilot - 71
External Pilot - 91
Power
Center
Plug-In (15407-2)
Non-Locking Overrides
Internal Pilot - 03
External Pilot - 53
Locking Overrides
Internal Pilot - 13
External Pilot - 23
Drop Cord (15407-1)
Non-Locking Overrides
Internal Pilot - 63
External Pilot - 83
Locking Overrides
Internal Pilot - 73
External Pilot - 93
Open
Center
Plug-In (15407-2)
Non-Locking Overrides
Internal Pilot - 07
External Pilot - 57
Locking Overrides
Internal Pilot - 17
External Pilot - 27
Drop Cord (15407-1)
Non-Locking Overrides
Internal Pilot - 67
External Pilot - 87
Locking Overrides
Internal Pilot - 77
External Pilot - 97
Dual 3-W
ay
2-Position
Plug-In (15407-2)
Non-Locking Overrides Internal Pilot - 07
Locking Overrides Internal Pilot - 17
Drop Cord (15407-1)
Non-Locking Overrides Internal Pilot - 67
Locking Overrides Internal Pilot - 77
Basic Size
Size 00 (18mm) 0
Size 0 (26mm) 1
Voltage
24 VDC W
120 VAC Z
* Be sure to choose Options from the correct list. For
example, if a Function of 4-Way 2-Position is chosen,
then only choose Options from the section listed for
that function. See the light gray-shaded columns of
the Function and Options lists.
