Ross Controls ROSS MODULAR I - Manual (Page 12)

12 © 2012, ROSS CONTROLS ® . All Rights Reserved.
Size 00 (18mm) & Size 0 (26mm) Common Model Numbers
Single Solenoid
2-Position
Double Solenoid
2-Position
Double Solenoid
3-Position Closed Center
3-Position Open Center
3-Position Power Center
4 2
5 3 1
Sol. 14
4 2
5 3 1
Sol. 14 Sol. 12
Series W66, Size 0 Series W66, Size 00 Series W66, Size 0 Series W66, Size 00
Series W66, Size 0
4 2
5 3
1
Open Center
#12 #14
4 2
5 3
1
Closed Center
#12 #14
4 2
5 3
1
Power Center
#12 #14
Series W66, Size 00
Series W66
Size 00
W6676A0401Z 120VAC
0.55 Cv
W6676A0401W 24VDC
Series W66
Size 0
W6676A1401Z 120VAC
1.1 Cv
W6676A1401W 24VDC
Power Center
Series W66
Size 00
W6677A0403Z 120VAC
0.50 Cv
W6677A0403W 24VDC
Series W66
Size 0
W6677A1403Z 120VAC
1.0 Cv
W6677A1403W 24VDC
Closed Center
Series W66
Size 00
W6677A0401Z 120VAC
0.50 Cv
W6677A0401W 24VDC
Series W66
Size 0
W6677A1401Z 120VAC
1.0 Cv
W6677A1401W 24VDC
Open Center
Series W66
Size 00
W6677A0407Z 120VAC
0.50 Cv
W6677A0407W 24VDC
Series W66
Size 0
W6677A1407Z 120VAC
1.0 Cv
W6677A1407W 24VDC
Series W66
Size 00
W6676A0407Z 120VAC
0.55 Cv
W6676A0407W 24VDC
Series W66
Size 0
W6676A1407Z 120VAC
1.1 Cv
W6676A1407W 24VDC
Plug-in, Series W66 (15407-2)
Remote Pressure Control Models Available (2 & 3-Position) – Consult ROSS
