NANO-CV-D25502/N26002 EPIC SBC
Page 52
4.8 Heat Sink Enclosure
WARNING:
Never run the NANO-CV-D25502/N26002 without the heat sink
secured to the board. The heat sink ensures the system remains cool
and does not need addition heat sinks to cool the system.
WARNING:
When running the NANO-CV-D25502/N26002, do not put the
NANO-CV-D25502/N26002 directly on a surface that can not dissipate
system heat, especially the wooden or plastic desk. It is highly
recommended to run the NANO-CV-D25502/N26002
on a heat dissipation surface or
using copper pillars to hold the board up from the desk below
When the NANO-CV-D25502/N26002 is shipped it is secured to a heat sink with eight
retention screws. If the NANO-CV-D25502/N26002 must be removed from the heat sink,
the eight retention screws must be removed.
