NANO-CV-D25502/N26002 EPIC SBC
Page 7
Specification/Model NANO-CV-D25502/N26002
COM
Three RS-232
One RS-422/485
Digital I/O One 8-bit digital input/output connector (4-bit input/4-bit output)
Fan
One 3-pin CPU fan connector
One 3-pin system fan connector
Front Panel One 10-pin header (power LED, HDD LED, power button, reset button)
Keyboard/Mouse One internal 6-pin wafer connector
SATA
Two SATA 3Gb/s ports with 5V power connectors (SATA1 and mSATA
share SATA signal)
USB
Six USB 2.0/1.1 devices supported:
Four by external connectors
Two by on-board pin header
Power Supply
9V~28V
AT and ATX support
One internal 4-pin (2x2) power connector
Power Consumption
12V @ 1.59 A (1.86 GHz Intel® Atom™ D2550 CPU with 4 GB 1333
MHz DDR3 SO-DIMM)
12V @ 1.23 A (1.6 GHz Intel® Atom™ N2600 CPU with 4 GB 1333 MHz
DDR3 SO-DIMM)
Operating
Temperature
D2550: -20ºC ~ 60ºC with free air; -20ºC ~ 70ºC with force air
N2600/N2800: -20ºC ~ 70ºC with free air; -20ºC ~ 75ºC with force air
Storage Temperature
D2550: -30ºC ~ 80ºC
N2600/N2800: -30ºC ~ 85ºC
Humidity (Operating) 5% ~ 95% (non-condensing)
Dimensions 115 mm x 165 mm
Weight (GW/NW) 850 g/350 g
Table 1-2: NANO-CV-D25502/N26002 Specifications
