NANO-CV-D25502/N26002 EPIC SBC
Page 14
Connector Type Label
Backlight inverter connector 5-pin wafer INV1
Battery connector 2-pin wafer CN1
Digital Input/Output (DIO) connector 10-pin header DIO1
Fan connectors 3-pin wafer CPU_FAN1,
SYS_FAN2
Front panel connector 10-pin header F_PANEL1
Keyboard and mouse connector 6-pin wafer KB_MS1
LVDS connector 20-pin crimp LVDS1
PCIe Mini card slots 52-pin PCIe Mini M_PCIE1,
M_PCIE2
Power connector (9V~28V) 4-pin connector CN2
RS-232 serial port connectors 10-pin header COM1, COM2,
COM3
RS-422/485 serial port connector 4-pin wafer COM4
Serial ATA (SATA) drive connectors 7-pin SATA SATA1, SATA2
SO-DIMM connector SO-DIMM connector DIMM1
USB 2.0 connector 8-pin header USB4
Table 3-1: Peripheral Interface Connectors
3.1.3 External Interface Panel Connectors
The table below lists the connectors on the external I/O panel.
Connector Type Label
Ethernet connectors RJ-45 LAN1, LAN2
USB connectors USB 2.0 USB_CON2,
USB_CON3
VGA connectors 15-pin female VGA1, VGA2
Table 3-2: Rear Panel Connectors
