NANO-CV-D25502/N26002 EPIC SBC
Page 2
1.1 Introduction
Figure 1-1: NANO-CV-D25502/N26002
The NANO-CV-D25502/N26002 EPIC motherboard is an Intel® Atom™ D2550/N2600
processor platform that supports one 1066 MHz or 800 MHz DDR3 SO-DIMM memory.
The NANO-CV-D25502/N26002 supports dual VGA display output and comes with a
LVDS connector supporting 24-bit or 18-bit LVDS screens. Maximum six USB ports, two
SATA 3Gb/s connectors, two PCIe Mini card slots, four COM ports, and one audio
connector provide flexible expansion options.
1.2 Model Variations
The model variations of the NANO-CV-D25502/N26002 are listed below.
Model No. CPU
NANO-CV-D25502-R10 Intel® Atom™ D2550 1.86 GHz
NANO-CV-N26002-R10 Intel® Atom™ N2600 1.6 GHz
NANO-CV-N28002-R10 Intel® Atom™ N2800 1.86 GHz
Table 1-1: NANO-CV-D25502/N26002 Model Variations
1.3 Features
Some of the NANO-CV-D25502/N26002 motherboard features are listed below:
EPIC form factor
