NANO-CV-D25502/N26002 EPIC SBC
Page 126
Partition 1: /
Partition 2: SWAP
NOTE:
Please reserve enough space for partition 3 for saving recovery
images.
Figure B-31: Partitions for Linux
Step 3: Create a recovery partition. Insert the recovery CD into the optical disk drive.
Follow Step 1 ~ Step 3 described in Section
78
B.2.2. Then type the following
commands (marked in red) to create a partition for recovery images.
system32> diskpart
DISKPART> list vol
DISKPART> sel disk 0
DISKPART> create part pri size= ___
DISKPART> assign letter=N
DISKPART> exit
system32> format N: /fs:ntfs /q /v:Recovery /y
system32> exit .
Step 4: Build-up recovery partition. Press any key to boot from the recovery CD. It will
take a while to launch the recovery tool. Please be patient. When the recovery
tool setup menu appears, type <3> and press (
78
Figure B-32). The
Symantec Ghost window appears and starts configuring the system to build-up a
