NANO-CV-D25502/N26002 EPIC SBC
Page 6
1.7 Technical Specifications
The NANO-CV-D25502/N26002 technical specifications are listed below.
Specification/Model NANO-CV-D25502/N26002
Form Factor EPIC
System CPU
1.86 GHz Intel® Atom™ D2550 dual-core CPU
1.6 GHz Intel® Atom™ N2600 dual-core CPU
1.86 GHz Intel® Atom™ N2800 dual-core CPU (optional)
System Chipset Intel® NM10
Memory
D2550/N2800: One 1066 MHz DDR3 SO-DIMM support (up to 4 GB)
N2600: One 800 MHz DDR3 SO-DIMM support (up to 2 GB)
Graphics Engine
D2550/N2800: Intel® GMA 3650 with 640 MHz graphics core speed
N2600: Intel® GMA 3600 with 400 MHz graphics core speed
Display
Dual display supported
First VGA is integrated in the CPU (1920 x 1200)
Second VGA is driven by the NXP PTN3392 (1920 x 1200)
One LVDS is integrated in the CPU:
D2550: 24-bit single-channel LVDS up to 1440 x 900
N2600/N2800: 18-bit single-channel LVDS up to 1366 x 768
Ethernet
Two Realtek RTL8111E PCIe GbE controllers
(LAN1 with ASF 2.0 support)
BIOS UEFI BIOS
Super I/O Controller Fintek F81866
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansion
One full-size PCIe Mini card slot with mSATA support (SATA1 and
mSATA share SATA signal)
One half-size PCIe Mini card slot
Audio
Realtek ALC662 HD Audio codec
One internal audio connector (10-pin box header)
