NANO-HM650 EP IC S BC
P a g e 77

Auto D EFAULT The serial port IO port address and interrupt address
are automatically detected.

IO=2E0h;
IRQ=10
Serial Port I/O port address is 2E0h and the interrupt
address is IRQ10

IO=2C0h;
IRQ=10, 11
Serial Port I/O port address is 2C0h and the interrupt
address is IRQ10, 11

IO=2C8h;
IRQ=10, 11
Serial Port I/O port address is 2C8h and the interrupt
address is IRQ10, 11

IO=2D0h;
IRQ=10, 11
Serial Port I/O port address is 2D0h and the interrupt
address is IRQ10, 11

IO=2E0h;
IRQ=10, 11
Serial Port I/O port address is 2E0h and the interrupt
address is IRQ10, 11
5.3.7 H/W Mo n ito r
The H/W Monitor menu (BIOS Menu 9) shows the operating temperature, fan speeds and
system voltages.
Aptio Setup Utility – Copyright (C) 2009 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+53 C
SYS Temperature1 :N/A
SYS Temperature2 :+29 C
VCC3V :+3.296 V
V_core :+1.056 V
+1.05V :+1.512 V
VDDR :+1.616 V
VSB3V :+3.312 V
VBAT :+3.184 V
5VSB :+4.968 V
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save
ESC Exit
Version 2.00.1201. Copyright (C) 2009 American Megatrends, Inc.
BIOS Menu 10: Hardware Health Configuration
