Page 59

NANO-HM650 EP IC S BC

P a g e 44

Figure 4-2: Lock the CPU Socket Retention Screw

4.3.2 Co o lin g Kit In s ta lla tio n

Figure 4-3: IEI CF-989A-RS Cooling Kit

An IEI Socket 989A CPU cooling kit can be purchased separately. (See Chapter 3) The

cooling kit comprises a CPU heat sink and a cooling fan.

WARNING:

Do not wipe off (accidentally or otherwise) the pre-sprayed layer of

thermal paste on the bottom of the heat sink. The thermal paste

between the CPU and the heat sink is important for optimum heat

dissipation.
