NANO-HM650 EP IC S BC
P a g e 6
1.5 Te c h n ic a l S p e c ific a tio n s
NANO-HM650 technical specifications are listed in table below.
S p e c ific a tio n NANO-HM650
Fo rm Fa c to r EPIC SBC
S o c ke t Socket G2
CP U S u p p o rte d Intel® Core™ i7/i5/i3 and Celeron® mobile processor
S ys te m Ch ip s e t Intel® HM65
Me m o ry One 204-pin 1066/1333 DDR3 SO-DIMM supported (system
max. 8GB)
Au d io Realtek ALC662 HD codec
LAN Dual PCIe LAN controller by Realtek RTL8111E with ASF 2.0
support
S u p e r I/O Fintek F81866
BIOS UEFI BIOS
P ro g ra m m a b le GP IO 8-bit digital I/O
Wa tc h d o g Tim e r Software programmable supports 1~255 sec. system reset
Exp a n s io n
P CIe One mini PCIe card slot
P CI-104 One PCI-104 slot
I/O In te rfa c e Co n n e c to rs
Au d io Co n n e c to r One internal audio connector via 10-pin header
Dis p la y P o rts Analog CRT by VGA connector (2048x1536)
18/24 bits Dual channel LVDS (1600x1200)
HDMI supports resolution up to 1080p
Eth e rn e t Two RJ-45 GbE ports
S e ria l P o rts Two RS-232 via 10-pin header
One RS-422/485 via 4-pin wafer
