NANO-HM650 EP IC S BC
P a g e 15
TPM connector 20-pin connector TPM1
USB connector 8-pin header USB4_5,USB8_9
Table 3-1: Peripheral Interface Connectors
3.1.3 Exte rn a l In te rfa c e P a n e l Co n n e c to rs
The table below lists the connectors on the external I/O panel.
Connector Type Label
Ethernet connectors RJ-45 LAN1，LAN2
HDMI connector HDMI port HDMI1
USB connectors USB port USB0_1，USB2_3
VGA connector 15-pin Female VGA1
Table 3-2: Rear Panel Connectors
3.2 In te rn a l P e rip h e ra l Co n n e c to rs
The section describes all of the connectors on the NANO-HM650.
3.2.1 Au d io Co n n e c to r
CN La b e l: AUDIO1
CN Typ e : 10-pin header
CN Lo c a tio n : See Figure 3-2
CN P in o u ts : See Table 3-3
The audio connector is connected to external audio devices including speakers and
microphones for the input and output of audio signals to and from the system.
