NANO-HM650 EP IC S BC
P a g e 59
4.6.1 HDMI Dis p la y De vic e Co n n e c tio n
The NANO-HM650 has one female HDMI connector on the external peripheral interface
panel. The HDMI connectors are connected to digital display devices. To connect a digital
display device to the NANO-HM650, please follow the instructions below.
S te p 1: Locate the HDMI connector. The location of the HDMI connector is shown in
another chapter.
S te p 2: Align the HDMI connector. Align the male HDMI connector on the digital
display device cable with the female HDMI connector on the external peripheral
interface.
S te p 3: Insert the HDMI connector . Once the connectors are properly aligned with the
male connector, insert the male connector from the digital display device into the
female connector on the NANO-HM650.
S te p 4: Secure the connector. Secure the HDMI connector from the digital display
device to the external interface by tightening the two retention screws on either
side of the connector. S te p 0:
4.6.2 LAN Co n n e c tio n
There are two external RJ-45 LAN connectors. The RJ-45 connector enables connection
to an external network. To connect a LAN cable with an RJ-45 connector, please follow
the instructions below.
S te p 1: Locate the RJ-45 connectors. The location of the LAN connector is shown in
Chapter 4.
S te p 2: Align the connectors. Align the RJ-45 connector on the LAN cable with one of
the RJ-45 connectors on the NANO-HM650. See Figure 4-17.
