5.5 Bo o t
Use the Boot menu (BIOS Menu 16) to configure system boot options.
Aptio Setup Utility – Copyright (C) 2009 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
Boot Configuration
Bootup NumLock State [On]
Quiet Boot
[Enabled]
Boot Option Priorities
Select the keyboard
NumLock state
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save
ESC Exit
Version 2.00.1201. Copyright (C) 2009 American Megatrends, Inc.
BIOS Menu 17: Boot
 Bo o tu p Nu m Lo ck [On ]
Use the Bootup NumLock BIOS option to specify if the number lock setting must be
modified during boot up.

Off Does not enable the keyboard Number Lock automatically. To
use the 10-keys on the keyboard, press the Number Lock key
located on the upper left-hand corner of the 10-key pad. The
Number Lock LED on the keyboard lights up when the Number
Lock is engaged.

On D EFAULT Allows the Number Lock on the keyboard to be enabled
automatically when the computer system boots up. This allows
the immediate use of the 10-key numeric keypad located on
the right side of the keyboard. To confirm this, the Number
Lock LED light on the keyboard is lit.
 Qu iet Bo o t [En ab led ]
Use the Quiet Boot BIOS option to select the screen display when the system boots.
