1440x900 48bit Sets the panel type to 1440x900 48bit

1600x900 48bit Sets the panel type to 1600x900 48bit

1680x1050 48bit Sets the panel type to 1680x1050 48bit

1920x1080 48bit Sets the panel type to 1920x1080 48bit

1920x1200 48bit Sets the panel type to 1920x1200 48bit
5.4.2 S o u th b rid g e Co n fig u ra tio n
Use the Southbridge Configuration menu (BIOS Menu 14) to configure the Southbridge
chipset.
Aptio Setup Utility – Copyright (C) 2009 American Megatrends, Inc.
Chipset
SouthBridge Configuration
Auto Power Button Status
[OFF]
PCH LAN Controller [Enabled]
Azalia [Enabled]
Azalia Internal HDMI Codec [Enabled]
Restore AC Power Loss [Last State]
Enabled or disabled
onboard NIC.
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save
ESC Exit
Version 2.00.1201. Copyright (C) 2009 American Megatrends, Inc.
BIOS Menu 16:Southbridge Chipset Configuration
 PCH LAN Co n tro lle r [En a b led ]
Use the PCH LAN Controller option to enable or disable the PCH LAN controller.

Disabled The onboard PCH LAN controller is disabled

Enabled D EFAULT The onboard PCH LAN controller is enabled
 Azalia [En ab led ]
Use the Azalia HD Audio option to enable or disable the High Definition Audio controller.
