NANO-HM650 EP IC S BC

P a g e 38

PIN

DESCRIPTION

PIN

DESCRIPTION

1

RED

2

GREEN

3

BLUE

4

NC

5

GND

6

GND

7

GND

8

GND

9

VGAVCC

10

HOTPLUG

11

NC

12

DDCDAT

13

HSYNC

14

VSYNC

15

DDCCLK

Table 3-25: VGA Connector Pinouts
