NANO-HM650 EP IC S BC

P a g e 16

Figure 3-2: Audio Connector Location

P IN NO.

DES CRIP TION

P IN NO.

DES CRIP TION

1

LFRONT-R

2

LLINE-R

3

GND

4

GND

5

LFRONT-L

6

LLINE-L

7

GND

8

GND

9

LMIC1-CONN-R

10

LMIC1-CONN-L

Table 3-3: Audio Connector Pinouts

3.2.2 Ba c klig h t In ve rte r Co n n e c to r

CN La b e l:

INV1

CN Typ e :

5-pin wafer

CN Lo c a tio n :

See Figure 3-3

CN P in o u ts :

See Table 3-4

The backlight inverter connector provides power to an LCD panel.
