IEI Integration NANO-9452 v1.00 User Manual
Page 7
Page vii
4.1.2 Peripheral Interface Connectors ..................................................................... 31
4.1.3 External Interface Panel Connectors............................................................... 32
4.2 I
NTERNAL
P
ERIPHERAL
C
ONNECTORS
...................................................................... 33
4.2.1 +12V ATX Power Supply Connector ............................................................... 33
4.2.2 +5V ATX Power Supply Connector ................................................................. 34
4.2.3 ATX Power Supply Enable Connector ............................................................. 35
4.2.4 Audio Connector (9-pin) .................................................................................. 36
4.2.5 Compact Flash Socket...................................................................................... 37
4.2.6 Digital Input/Output (DIO) Connector............................................................ 40
4.2.7 Fan Connector (+12V) .................................................................................... 40
4.2.8 Front Panel Connector (12-pin) ...................................................................... 41
4.2.9 IDE Connector(44-pin).................................................................................... 43
4.2.10 Infrared Interface Connector (5-pin) ............................................................. 44
4.2.11 Keyboard/Mouse Connector........................................................................... 45
4.2.12 LVDS LCD Connector ................................................................................... 46
4.2.13 Mini PCIe Socket ........................................................................................... 48
4.2.14 Parallel Port Connector ................................................................................ 50
4.2.15 PCI-104 Slot................................................................................................... 51
4.2.16 SATA Drive Connectors ................................................................................. 54
4.2.17 Serial Port Connector (COM 2)(RS-232, RS-422 or RS-485) ....................... 55
4.2.18 Serial Port Connector (COM 3 and COM 4)................................................. 56
4.2.19 TV Out Connector .......................................................................................... 57
4.2.20 USB Connectors (Internal) ............................................................................ 58
4.3 E
XTERNAL
P
ERIPHERAL
I
NTERFACE
C
ONNECTOR
P
ANEL
......................................... 59
4.3.1 Keyboard/Mouse Connector ............................................................................ 59
4.3.2 LAN Connectors............................................................................................... 60
4.3.3 Serial Port Connector ...................................................................................... 61
4.3.4 USB Connector ................................................................................................ 62
4.3.5 VGA Connector ................................................................................................ 63
5
INSTALLATION .................................................................................................... 65
5.1 A
NTI
-
STATIC
P
RECAUTIONS
...................................................................................... 66
5.2 I
NSTALLATION
C
ONSIDERATIONS
............................................................................. 67
5.2.1 Installation Notices .......................................................................................... 67
5.2.2 Installation Checklist ....................................................................................... 68
