NANO-9452 EPIC Motherboard
Page 16
Specification Ultra ATA/100 Ultra ATA/66 Ultra ATA/100
PIO Mode 0 – 4 0 – 4 0 – 4
PIO Max Transfer Rate 16.6 MB/s 16.6 MB/s 16.6 MB/s
DMA/UDMA designation UDMA 3 - 4 UDMA 3 – 4 UDMA 2
DMA/UDMA Max Transfer 100MB/s 66MB/s 33MB/s
Controller Interface 5V 5V 5V
Table 2-3: Supported HDD Specifications
2.6.4 Intel
®
ICH7M Low Pin Count (LPC) Interface
The ICH7M LPC interface complies with the LPC 1.1 specifications. The LPC bus from the
ICH6 is connected to the following components:
BIOS chipset
Super I/O chipset
2.6.5 Intel
®
ICH7M PCI Interface
The PCI interface on the ICH7M is compliant with the PCI Revision 2.3 implementation.
Some of the features of the PCI interface are listed below.
PCI Revision 2.3 compliant
33MHz
5V tolerant PCI signals (except PME#)
Integrated PCI arbiter supports up to seven PCI bus masters
2.6.6 Intel
®
ICH7M Real Time Clock
256 bytes of battery backed RAM is provided by the Motorola MC146818A real time clock
(RTC) integrated into the ICH6. The RTC operates on a 3V battery and 32.768KHz crystal.
The RTC keeps track of the time and stores system data even when the system is turned
off.
