NANO-9452 EPIC Motherboard
Page 48
4.2.13 Mini PCIe Socket
CN Label:
CN4
CN Type:
26-pin box header
CN Location:
See
CN Pinouts:
See
The 52-pin mini PCIe socket supports the latest PCIe extension cards such as wireless
LAN cards and other compatible devices.
Figure 4-15: Mini PCIe Connector Pinout Locations
