NANO-9452 EPIC Motherboard
Page 119
Temperature 3 Limit of Start [020]
WARNING:
Setting this value too high may cause the fan to start only when the
CPU is at a high temperature and therefore cause the system to be
damaged.
The Temperature 3 Limit of Start option can only be set if the CPU FAN Mode Setting
option is set to Automatic Mode. Use the Temperature 3 Limit of Start option to select
the CPU temperature at which the cooling fan should automatically turn on. When the fan
starts, it rotates using the starting pulse width modulation (PWM) specified in the Fan 3
Start PWM option below. To select a value, select the Temperature 3 Limit of Start
option and enter a decimal number between 000 and 127. The temperature range is
specified below.
Minimum Value: 0°C
Maximum Value: 127°C
Temperature 3 Limit of Full [080]
WARNING:
Setting this value too high may cause the fan to start rotating at full
speed only when the CPU is at a high temperature and therefore cause
the system to be damaged.
The Temperature 3 Limit of Full option can only be set if the CPU FAN Mode Setting
option is set to Automatic Mode. Use the Temperature 3 Limit of Full option to select
the CPU temperature at which the cooling fan starts to rotate at full speed. When the CPU
temperature exceeds the temperature specified in this option, the fan starts to rotate at full
