NANO-9452 EPIC Motherboard
Page 3
dual-channel LVDS
EPIC form factor
RoHS compliant
Supports AT and ATX power supplies
1.2 NANO-9452 Overview
1.2.1 NANO-9452 Overview Photo
The NANO-9452 has a wide variety of internal and external peripheral connectors. The
peripheral connectors are connected to devices including PCI-104 devices, mini PCIe
devices, storage devices, display devices and parallel communications devices. A labeled
photo of the peripheral connectors on the front of the NANO-9452 is shown in Figure 1-1.
Figure 1-1: NANO-9452 Overview [Front View]
A labeled photo of the peripheral connectors on the back of the NANO-9452 is shown in
Figure 1-1.
