NANO-9452 EPIC Motherboard
Page 31
Figure 4-2: Connector and Jumper Locations (Solder Side)
4.1.2 Peripheral Interface Connectors
Table 4-1 shows a list of the peripheral interface connectors on the WAFER-LX. Detailed
descriptions of these connectors can be found below.
Connector Type Label
+12V ATX power supply connector 4-pin ATX connector CN1 and CN2
+5V power connector 2-pin ATX connector CN3
ATX enable connector 3-pin wafer ATXCTL1
Audio connector 14-pin header J_AUDIO1
Compact Flash (CF) connector 50-pin header CF1
Digital I/O connector 10-pin header DIO1
Fan connector 3-pin wafer CPU_FAN1
