NANO-9452 EPIC Motherboard
Page 12
DDR2 only (DO NOT install a DDR SO-DIMM)
Single-channel or dual-channel
Capacities of 256MB, 512MB or 1GB
Transfer speeds of 533MHz, or 667MHz
64-bit wide channel
The memory socket is shown in Figure 2-4.
Figure 2-4: 200-pin SO-DIMM Socket
2.5.3 Intel
®
945GM Integrated Graphics
The Intel
®
945GM northbridge chipset has an Intel
®
Gen. 3.5 integrated graphics engine
that supports the following display devices:
Analog CRT
LVDS
TV-Out
S-DVO ports
