NANO-9452 EPIC Motherboard
Page 85
5.5.1 Airflow
WARNING:
Airflow is critical to the cooling of the CPU and other onboard
components. The chassis in which the NANO-9452 must have air vents
to allow cool air to move into the system and hot air to move out.
The NANO-9452 must be installed in a chassis with ventilation holes on the sides allowing
airflow to travel through the heat sink surface. In a system with an individual power supply
unit, the cooling fan of a power supply can also help generate airflow through the board
surface.
NOTE:
IEI has a wide range of backplanes available. Please contact your
NANO-9452 vendor, reseller or an IEI sales representative at
[email protected] or visit the IEI website ( http://www.ieiworld.com.tw )
to find out more about the available chassis.
5.5.2 Motherboard Installation
To install the NANO-9452 motherboard into the chassis please refer to the reference
material that came with the chassis.
5.6 Internal Peripheral Device Connections
5.6.1 Peripheral Device Cables
The cables listed in Table 5-8 are shipped with the NANO-9452.
