NANO-9452 EPIC Motherboard
Page 33
Connector Type Label
Ethernet connector RJ-45 LAN1
Ethernet connector RJ-45 LAN2
Keyboard and mouse connector PS/2 connector KB_MS1
RS-232 serial port connector Male DB-9 COM1
USB port USB port USB_C45
VGA port connector Female DB-15 VGA1
Table 4-2: Rear Panel Connectors
4.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible
when the motherboard is outside of the chassis. This section has complete descriptions of
all the internal, peripheral connectors on the NANO-9452.
4.2.1 +12V ATX Power Supply Connector
CN Label: CN1 and CN2
CN Type: 4-pin ATX power connector (1x4)
CN Location: See Figure 4-3
CN Pinouts: See Table 4-3
The 4-pin +12V ATX power supply connector is connected to a +12V ATX power supply.
