NANO-LX EPIC SBC

Figure 4-21: CN25 Connector Location

4.2.20 Reset Button Connector

CN Label:

CN6

CN Type:

2-pin header

CN Pinouts:

See Table 4-24

CN Location:

See Figure 4-22

The Reset Button connector connects to an external reset button through an adapter

cable.

PIN

DESCRIPTION

PIN

DESCRIPTION

1 RESET

BUTTON

+

2

RESET BUTTON -

Table 4-24: CN6 Connector Pinouts
