IEI Integration NANO-LX v1.10 - Manual (Page 24)

NANO-LX EPIC SBC
Page 24
SPECIFICATION
1 x IDE
6 x RS-232
1 x RS-422/485
2 x SATA channels
PC/104-Plus Interface Direct ISA DMA mode operation.
Infrared Support One Infrared Data Association (IrDA) interface
Real Time Clock 256-byte battery backed CMOS RAM
Hardware Monitoring CPU temperature and system voltages
Ethernet 10/100BASE-T RTL8100C
BIOS AWARD
Physical Dimensions 115mm x 165mm
Operating Temperature Minimum: 0ºC (32°F)
Maximum: 60°C (140°F)
Audio Interfaces AC’97 Codec Realtek ALC203
Table 1-1: Technical Specifications
1.3 Compatible Operating Systems and Memory Modules
The following sections lists the operating systems (OS) and memory modules that have
passed the test held by IEI. Please consider using these compatible OS and memory
modules with the NANO-LX for the best performance.
1.3.1 Operating System
The compatible operating systems include:
DOS 6.22
Windows XP
