NANO-LX EPIC SBC
Jumper Settings: See Table 5-8
Jumper Location: See Figure 5-4
The JP7 jumper sets the voltage to the LCD panel.
WARNING!
The LCD panel voltage select jumper setting of NANO-LX-800-R11 is
different from the previous version (NANO-LX-800-R10). Please
confirm the version number of the motherboard prior to setup the LCD
panel voltage select jumper (JP7).
Model No. Pin Description
Short 1-2 Panel Voltage select 5V
NANO-LX-800-R10
Short 2-3 Panel Voltage select 3.3V
Short 1-2 Panel Voltage select 3.3V
NANO-LX-800-R11
Short 2-3 Panel Voltage select 5V
Table 5-8: JP7 Jumper Settings
5.7 Chassis Installation
5.7.1 Airflow
WARNING:
Airflow is critical to the cooling of the CPU and other onboard
components. The chassis in which the NANO-LX must have air vents
to allow cool air to move into the system and hot air to move out.
The NANO-LX must be installed in a chassis with ventilation holes on the sides allowing
airflow to travel through the heat sink surface. In a system with an individual power supply
