IEI Integration NANO-LX v1.10 - Manual (Page 71)

NANO-LX EPIC SBC
Pin Row A Row B Row C Row D
30 SA1 OSC -- --
31 SA0 GND -- --
Table 4-20: CN7 (PC/104) Connector Pinouts
Pin A B C D
1 GROUND TBD1 +5V AD0
2 VIO AD2 AD1 +5V
3 AD5 GND AD4 AD3
4 CBE0- AD7 GND AD6
5 GND AD9 AD8 GND
6 AD11 VIO AD10 N66EV
7 AD14 AD13 GND AD12
8 +3.3V CBE1- AD15 +3.3V
9 SERR- GND SBO- PAR
10 GND PERR- +3.3V SDONE
11 STOP- +3.3V LOCK- GND
12 +3.3V TRDY- GND DEVSEL-
13 FRAME- GND IRDY- +3.3V
14 GND AD16 +3.3V CBE2-
15 AD18 +3.3V AD17 GND
16 AD21 AD20 GND AD19
17 +3.3V AD23 AD22 +3.3V
18 IDSEL0 GND IDSEL1- IDSEL2
19 AD24 CBE3- VIO IDSEL3
20 GND AD26 AD25 GND
21 AD29 +5V AD28 AD27
22 +5V AD30 GND AD31
23 REQ0- GND REQ1- VIO
24 GND REQ2- +5V GNT0-
25 GNT1- VIO GNT2- GND
26 +5V PCICLK0 GND PCICLK1
27 PCICLK2 +5V PCICLK3 GND
28 GND INTD- +5V PCIRST-
