NANO-LX EPIC SBC
Figure D-4: Sound Effects Manager (ALC203)
NOTE:
The Sound Effect Manager shown in Figure D-4 is for the RealTek ALC203
audio CODEC. Different CODECs may have different sound manager
appearances.
The following section describes the different configuration options in the Sound Effect
Manager.
D.2.2 Sound Effect Manager Configuration Options
The Sound Effects Manager enables configuration of the items listed below. To configure
these items click the corresponding menu tab in the Sound Effects Manager (Figure
D-4).
NOTE:
The Karaoke Mode is configured in the Sound Effect menu. To access
Karaoke configuration settings, click on the Sound Effect menu tab.
Sound Effect
Karaoke Mode
Equalizer
Speaker Configuration
Speaker Test
S/PDIF-In
S/PDIF-Out
Connector Sensing
HRTF Demo
