NANO-LX EPIC SBC

Figure 5-12: SATA Power Drive Connection

5.9 External Peripheral Interface Connection

The following external peripheral devices can be connected to the external peripheral

interface connectors.

RJ-45 Ethernet cable connectors

PS/2 devices

Serial port devices

USB devices

VGA monitors

To install these devices, connect the corresponding cable connector from the actual

device to the corresponding NANO-LX external peripheral interface connector making

sure the pins are properly aligned.

Page 108
