IMBA-Q454-R10 User Manual
Page 93
5.2 Main
The Main BIOS menu (Error! Reference source not found.) appears when the BIOS Setup
program is entered. The Main menu gives an overview of the basic system information.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
System Overview
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
AMIBIOS
Version :08.00.15
Build Date :02/27/08
ID: :B106MR10
Processor
Intel® Core(TM)2 CPU 6300 @ 1.866GHz
Speed :1866MHz
Count :1
System Memory
Size :1998MB
System Time
[14:20:27]
System Time [Tue 05/06/2008]
Use [ENTER], [TAB] or
[SHIFT-TAB] to select a
field.
Use [+] or [-] to
configure system time.
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 1: Main
Î System Overview
The System Overview lists a brief summary of different system components. The fields in
System Overview cannot be changed. The items shown in the system overview include:
ƒ AMI BIOS: Displays auto-detected BIOS information
o Version: Current BIOS version
o Build Date: Date the current BIOS version was made
o ID: Installed BIOS ID
ƒ Processor: Displays auto-detected CPU specifications
o Type: Names the currently installed processor
