Î Floppy A
Use the Floppy A/B option to configure the floppy disk drive. Options are listed below:
ƒ Disabled
ƒ 360 KB 51/4”
ƒ 1.2 MB 51/4”
ƒ 720 KB 31/2”
ƒ 1.44 MB 31/2’
ƒ 2.88 MB 31/2”
5.3.4 Super I/O Configuration
Use the Super I/O Configuration menu (Error! Reference source not found.) to set or
change the configurations for the FDD controllers, parallel ports and serial ports.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Configure Super I/O Chipset
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Serial Port1 Address
[3F8/IRQ4]
Serial Port2 Mode [Normal]
Serial Port2 Address [2F8/IRQ3]
Serial Port2 Mode [Normal]
Parallel Port Address [378]
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]
Serial Port3 Address [3E8]
Serial Port3 IRQ [10]
Serial Port4 Address [2E8]
Serial Port4 IRQ [10]
Serial Port5 Address [2FO]
Serial Port5 IRQ [10]
Serial Port6 Address [2E0]
Serial Port6 IRQ [10]
Allows BIOS to select
Serial Port Base
Addresses
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 7: Super IO Configuration
