98 Agilent E6474A User’s Guide
4 Use Your System
The cellsite data is displayed on a map view once logging is
started and your data collection is in the same geographical
region as the loaded cellsite database.
Figure 74 Add a cellsite layer button
How to add and configure an indoor map
The E6474A software supports indoor or in- building
measurements. These are measurements that have been
taken without the direct reference to GPS satellite signals.
When testing technologies that require accurate timing
references, it is recommended that you use a calibrated
timing source. Refer to
“Indoor Setup" on page 47 for more
information.
How to load and configure an indoor map
1 Open a map view.
2 In the properties panel, select Indoor Mapping Mode.
Refer to Figure 75 on page 99.
