Set Up Your System 3
Agilent E6474A User’s Guide 29
Agilent Digital Receivers
Overview
Agilent manufactures a range of digital RF receivers that
cover most technologies. All receivers are supplied with an
internal GPS systems. For technical details of the available
receivers, refer to
“Receiver Specifications" on page 151.
Receivers can be connected and configured using the
following methods:
Receiver configuration Refer to
Connecting a single W1314A receiver page 30
Connecting multiple W1314A receivers page 30
Using the power distribution module (PDM) (W1314A) page 32
Using the Diplexer antenna connector (W1314A) page 33
Connecting a single E645xC receiver page 34
Connecting multiple E645xC receivers page 35
Pulse trigger the E645xC receivers page 37
NOTE
For details on how to upgrade the Agilent receiver firmware, refer to
“Updating Receiver Firmware" on page 128.
