Set Up Your System 3
Agilent E6474A User’s Guide 33
Refer to “Installing the PDM in the Vehicle" on page 186 for
more information about PDM in- vehicle installation.
Using a Combiner antenna connection (Agilent W1314A)
Use a combiner to obtain signals from two different
antennas.
For some options of receivers, a single antenna cannot
provide coverage for all available bands. These receivers are
supplied with two antennas and a combiner. In situations
where multiple bands need to be scanned, you will need to
use the combiner to provide adequate RF signal strength.
Connect the receiver to the combiner unit using the SMA
(M) to N- Type (M) cable. Then connect the two antennas to
the combiner unit using the SMA (M) to N- Type (F)
connector adapters. Refer to
Figure 14 on page 34.
NOTE
The combiner and cables add insertion loss, slightly reducing the
sensitivity of the receiver.
