Specifications C
Agilent E6474A User’s Guide 173
Adjacent channel desensitization †
Adjacent channel rejection
‡
Internally generated spurious, input referred
– 25 dBm typical
45 dB typical
– 120 dBm
Input/Output RF input 50 Ω Type-N
Connectors Computer RS-232 (DB9) Male
GPS RS-232 (DB9) Male
Power DC power jack 100 mils, positive center
Miscellaneous Operating temperature range 0°C to 55°C
Maximum relative humidity 80% for temperatures up to 31°C, decreasing
linearly to 50% relative humidity at 40°C
Storage temperature range – 40°C to +70°C
Dimensions 6 in × 3-5/8 in × 8 in
15.24 cm x 9.21 cm x 20.32 cm
Weight 4.6 lbs (2.1 kg)
Power
Power (internal GPS, option 200) 9 to 34 V DC, 9W
9 to 34 V DC, 10W
Transformer AC Power (supplied with
receiver) 100 - 240 Volts AC 50 - 60 Hz
Internal GPS
**
(Option
200)
GPS Receiver 8 Channel internal GPS receiver
Connector type SMA
Differential compatible without dead reckoning
Note: Internal GPS is standard on all “C” receivers. It can be disabled if you wish to use an
external GPS system.
* It is recommended the input signal level not exceed – 40 dBm.
† Adjacent channel desensitization: 1 dB compression of tuned signal with interfering signal 1.25 MHz from tuned signal.
‡ Adjacent channel rejection applies to the narrowband mode (200 kHz IF filter) and is defined as: Suppression of interfering
signal ± 200 kHz from tuned signal for 200 kHz.
** Receivers (with the exception of “C” receivers) fitted with an internal GPS do not support connection to external GPS
receivers.
Item Description Specification
