PETracer ML User Manual Chapter 9: Reports and Tools
Teledyne LeCroy
169
9.6 Data Flow Window
The Data Flow window shows marker, packet, direction, type, length, address, payload,
handshake, and timestamp information.
To obtain the Data Flow window, select Report > Data Flow 
or click the Data Flow toolbar icon.
The toolbar allows you to:
• Expand the window to full screen or Collapse to a smaller window.
• Synchronize.
• Save.
• Select Data Flow columns to display and their widths:
• Marker
• Packet
• Direction
• Type
• Length
• Address
• Payload
• Handshake
• Time Stamp
