Chapter 8: Recording Options PETracer ML User Manual
132
Teledyne LeCroy
8.6 Recording Rule Limits
PETracer ML has finite buffer resources that limit the number of actions and events that
can be assigned for each recording channel. When creating complex event sequences,
it is possible to hit the limits of these resources and get an error message like the ones
shown in the screenshots below.
In addition to the following limitations, you should also be aware of how PETracer handles
user-created contradictory rules. See “Recording Rules Logic: How Contradictory Rules
are Resolved” on page 134 for an explanation.
In order to maximize the buffer allocation for recordings, Teledyne LeCroy has imposed
the following configuration limitations into PETracer ML.
Configuration Limitations in PETracer ML
• Up to four actions per state: No more than four actions can be assigned per state
or the error message shown below appears and the Status Indicator in the top right
of the dialog generates an Invalid Configuration status.

Example: Too many Actions per State. In this example, the actions are: three Filter
Outs, an Advance the Sequence, and a Count.
