Chapter 9: Reports and Tools PETracer ML User Manual
162
Teledyne LeCroy
Vertical zoom in
Vertical zoom out
Click and Drag zoom. Click and drag to zoom in on a part of the graph.
Select Range. Displays a dialog box for selecting a packet range.
Synchronize Graph Areas. If two or more graphs are displayed, this button
synchronizes the graphs to one another. Once synchronized, the positioning slider of
one graph moves the other graphs.
Graph Areas. Provides options for creating and displaying additional graphs of data
lengths, packet lengths, and percentage of bus used.
