PETracer ML User Manual Chapter 7: Display Options
Teledyne LeCroy
109
Configuration Name
Display Configuration Name: This field is used to enter a text string to be associated
with the current set of Display Options. This name is saved with the Display Options file,
and appears as part of the title of the packet view window that uses this set of Display
Options.
7.3 Color, Format, and Hiding Options
The Color/Format/Hiding tab allows you to customize the colors and formats associated
with each field in the CATC Trace and to selectively hide fields or packets. You access
these display options by selecting Setup > Display Options > Color/Format/Hiding
tab.
The Color/Format/Hiding property page lets you set how fields display in a CATC Trace.
This property page lets you set field color and data format (binary, hex, decimal, ASCII),
and lets you hide selected fields from the display.
