40
6. Specifications
6. Specifications
(1) Max. speed
The maximum speed for this ROBO Cylinder is limited due to the sympathetic vibration of the ball screw shaft
and the limitation of motor rotation speed.
Do not exceed the maximum speed shown in the table below.
Strokes and maximum speed limits (Unit: mm/s)
Model name Motor type Lead [mm]
Stroke [mm]
20 30 40 50 60 70 80 90 100
TA4 10W
2 100
4 200
6 300
(Note) The maximum speed may not be reached depending on the acceleration/deceleration setting.
Strokes and maximum speed limits (Unit: mm/s)
Model name Motor type Lead [mm]
Stroke [mm]
25 50 75 100
TA5 20W
2.5 125
5 250
10 465 <400>
(Note) The maximum speed may not be reached depending on the acceleration/deceleration setting.
Values in < > are for when mounted vertically.
Strokes and maximum speed limits (Unit: mm/s)
Model name Motor type Lead [mm]
Stroke [mm]
25 50 75 100 125 150
TA6 20W
3 150
6 300
12 560 <500>
(Note) The maximum speed may not be reached depending on the acceleration/deceleration setting.
Values in < > are for when mounted vertically.
Strokes and maximum speed limits (Unit: mm/s)
Model name Motor type Lead [mm]
Stroke [mm]
25 50 75 100 125 150 175 200
TA7 30W
3 150
6 300
12 600 <580>
(Note) The maximum speed may not be reached depending on the acceleration/deceleration setting.
Values in < > are for when mounted vertically.
