TAI Model 6200A SO
2
Analyzer Operator Manual, 02164, Rev. G
6.8.3 TEST Commands and Messages
Table 6-10: RS-232 Test Messages
Name Message Description
RANGE 1 RANGE=xxxxx PPB 2 Analyzer range
STABILITY STABIL=xxxx.x PPB Std. Deviation of last 25 SO
2
concentration values
SAMPPRESS PRES=xxx.x IN-HG-A Sample pressure
SAMPFLOW SAMPLE FL=xxx CC/M Sample flow rate
PMTDET PMT=xxxxxx MV PMT output
UVDET UV LAMP=xxxx MV Instantaneous UV lamp reading
STRAYLIGHT STR LGT=xxx.x PPB Stray light level
DARKPMT DRK PMT=xx.x MV PMT dark current in MV
DARKLAMP DRK LMP=xx.x MV UV detector dark current in MV
SLOPE SLOPE=x.xxx Calibration slope parameter
OFFSET OFFSET=xxx.x MV Calibration offset parameter
HVPS HVPS=xxxxx V High voltage power supply
DCPS DCPS=xxxxxx MV DC power supply
RCELLTEMP RCELL TEMP=xxx C Reaction cell temperature
BOXTEMP BOX TEMP=xxx C Internal box temperature
PMTTEMP PMT TEMP=xxx C PMT temperature
IZSTEMP 3 IZS TEMP=xxxx C IZS temperature
TESTCHAN 4 TEST=xxxx.x MV Test channel output
CLOCKTIME TIME=HH:MM:SS Time of day
1 Displayed when single or autorange is enabled.
2 Depends on which units are currently selected.
3 Only if option installed.
4 Only if test channel selected.
6-17
