2.5 Installation
The 6200A comes in two chassis. There is a power cord for each that should be plugged into the correct
voltage and frequency receptacle. See the tag on the rear panel of each chassis for the voltage and
frequency settings. The power connection must be made by an approved three-wire-grounded power cord.
The pneumatic connections are shown in Figure 2.5.
•
Connection to the TRS analyzer must be made with Teflon or stainless steel tubing.
•
Connect the sample inlet to the labeled fitting.
•
The sample exhaust must be routed to a well ventilated area away from the air inlet for the zero
air scrubber on the rear panel.
The overall pneumatic diagrams of the Model 6200A are shown in Figures 2.1, 2.2, and 2.3.
CAUTION !
DO NOT BLOCK THE SIDE AND BACK
VENTILATION OF THE M501TRS
CONVERTER
