TAI Model 6200A SO
2
Analyzer Operator Manual, 02164, Rev. G
Table 6-6: RS-232 Terminal Mode Editing Keys
Key Function
CR (carriage return) Execute command
BS (backspace) Backspace one character to the left
ESC (escape) Erase entire line
Control-R (ASCII 18 decimal) Recall previous command
Control-E (ASCII 5 decimal) Recall and execute previous command
Commands are not case-sensitive; you should separate all command elements (i.e. keywords, data
values, etc.) by spaces.
Words such as T, SET, LIST, etc. are called keywords and are shown on the help screen in
uppercase, but they are not case-sensitive. You must type the entire keyword; abbreviations are not
accepted.
OBTAINING HELP
Typing "?" followed by Return or Enter will cause a help screen to be displayed.
6.8.2 Command Summary
The information contained in the rest of this section covers all of the normal commands that are
required to operate the instrument from a remote terminal. If you are going to be writing computer
programs to communicate with the 6200A (i.e., operating the port in COMPUTER MODE) we
suggest that you order a supplementary manual "The RS-232 Interface". This manual shows
additional features of the port designed to support a computer driven interface program.
6-13
