Analyzer Operator Manual, 02164, Rev. G
Table 9-4: Diagnostic Mode - Signal I/O (Continued)
No Signal Control Description
19 ST_DIAG_MODE YES Status Bit - In Diagnostic mode
Logic High = 6200A in Diagnostic mode
Logic Low = Not in Diagnostic mode
20 ST_POWER_OK YES Status Bit - Power OK
Logic High = Instrument power is on
Logic Low = Instrument power is off
21 ST_SYSTEM_OK YES Status Bit - System OK
Logic High = No instrument warning present
Logic Low = 1 or more alarm present
22 ST_HVPS_ALARM YES Status Bit - HVPS alarm
Logic High = HVPS out of spec
Logic Low = HVPS within spec
23 PMT_SIGNAL NO Current PMT voltage. Same as PMT voltage in TEST
menu. Bi-polar, typically in 0-5000mV range. A
constant value of 5000mV indicates offscale.
24 RCELL_TEMP NO Reaction Cell temperature. 3500 mV for 50 o C.
25 BOX_TEMP NO Box Temperature. Typically 1800 mV for 25 o C.
26 IZS_TEMP NO IZS permeation tube oven temp. Typically 3500 mV
for 50
o C.
27 PMT_TEMP NO PMT cold block temperature. Typically 4300 mV for
7
o C.
28 DCPS_VOLTAG NO DC power supply composite voltage output.
Typically 2500 mV.
29 SAMPLE_PRES NO Sample pressure in mV. Typical sea level value =
4300mV for 29.9" HG-A.
30 SAMPLE_FLOW NO Sample flow in mV. Typical value is about 3200 mV
for 650cc/min.
31 HVPS_VOLTAG NO HVPS programming voltage. Output of HVPS is
1000x value present.
32 DAC_CHAN_0 NO Output of SO
2
(DAC0/RANGE1) in mV.
33 DAC_CHAN_1 NO Output of SO
2
(DAC1/RANGE2) in mV.
(table continued)
9-15
