2.0 INTRODUCTION
This manual addendum should be used in conjunction with the standard Model 6200A.
2.1 Specifications
2.1.1 Analyzer Specifications
The specifications for the SO2 analyzer are contained in the standard Model 6200A manual.
2.1.2 M501TRS Converter Specifications
TABLE 2.1 – M501TRS Converter Specifications
Specification Value Unit
Flow Rate 1000 Cc/min maximum
TRS Concentration 20 ppm
Converter Temperature 950 – 1050
o
C
Dilution Ratio 4.3:1 Number
Conversion Eff. (H2S) >98 %
Power 220 VAC, 50/60 Hz, 220 watts
Weight 24 lbs
11 kg
Dimensions 7 x 17 x 22 inches
178 x 432 x 559 mm
