APPROVED OPTIONS
The following optional accessories as listed in Chapter 1.0 of the Instruction Manual are suitable for
use in Division 2.
•
6DI/4DO, Contact Closure Input (CCI), Contact Closure Output (CCO).
•
Dual Relay ITB, CCO.
WARNING
For use in Division 2 locations, the energy to relay contacts 8
and 11 must be limited to <3 VA, <28 V and <250 mA, resistive
loads only.
The use of open contact type relays in a Class I, Division 2 loca-
tions is permitted only if the energy switched by the contacts is lim-
ited to an intrinsically safe level. It is the user’s responsibility to
limit the energy.
•
16DI/DO ITB, for Opto 22 I/O modules.
•
Opto 22 I/O modules:
The following modules are suitable for use in Class I, Division 2 locations as part of
the 16DI/DO ITB.
Opto 22 Part Number
AC Input
Modules
AC Output
Modules
DC Input
Modules
DC Output
Modules
G4IDC5
G4IDC5G
G4IAC5
G4IAC5A
G4IDC24
G4IAC24 G4OAC5
G4OAC5A
G4OAC5A5(NC)
G4OAC24
G4OAC24A G4IC5
G4IDC5B
G4IDC5D
G4IDC5G
G4IAC5
G4IAC5A
G4IDC24
G4IAC24 G4ODC5
G4ODC5A
G4ODC24
WARNING
It is the user’s responsibility to install all associated switches
and load apparatus in accordance with ANSI/NFPA 70, National
Electrical Code. Rules and requirements for the installation and
wiring of equipment in Class I, Division 2 Hazardous (Classified)
Locations are found in Article 501 of the Code.
MODULAR CONTROLLER QUICK START
A-2
