Micromod Micro-DCI: 53MC5000 Multi-Loop Process Controller Installation User Manual
Page 41
When the Module Mode configuration is complete, the controller may be returned to the operator
mode either by pressing the F1 key to step backwards through the menus or by pressing the
MODE key .
The following chart is a representation of the Module-Mode menu structure:
MODULAR CONTROLLER QUICK START
3-16
